Feature |
S5560S-28P-SI |
S5560S-52P-SI |
S5560S-28S-SI |
S5560S-52S-SI |
|
Box switching capacity |
598Gbps |
|||
|
Port switching capacity |
56Gbps |
104Gbps |
128Gbps |
176Gbps |
|
Forwarding capacity |
42Mpps |
78Mpps |
96Mpps |
132Mpps |
|
CPU |
1 Core, 800MHz |
|||
|
Flash/SDRAM |
512MB/256MB |
|||
|
Dimensions (H × W × D) |
43.6 × 440 × 160 mm |
43.6 × 440 × 230 mm |
43.6 × 440 × 160 mm |
43.6 × 440 × 230 mm |
|
Weight |
< 2.5 kg |
< 3.5 kg |
< 2.5 kg |
< 3.5 kg |
|
Management port |
1 console port |
|||
|
Maximum stacking num |
9 |
|||
|
Stacking bandwidth |
16Gbps |
80Gbps |
||
|
Networking interface |
24 × 10/100/1000Base-T autosensing Ethernet ports 4 × SFP ports |
48 × 10/100/1000Base-T autosensing Ethernet ports 4 × SFP ports |
24 × 10/100/1000Base-T autosensing Ethernet ports 4 × 10G SFP+ ports |
48× 10/100/1000Base-T autosensing Ethernet ports 4 × 10G SFP+ ports |
|
Port Surge |
6KV |
6KV |
6KV |
6KV |
|
Input voltage |
AC: The rated voltage range is 100V to 240V, 50/60Hz. |
|||
|
Total power consumption |
MIN: AC 9W MAX: AC 23W |
MIN: AC 18W MAX: AC 41W |
MIN: AC 10W MAX: AC 24W |
MIN: AC 19W MAX: AC 44W |
|
Fan number |
Fan-less |
1 |
1 |
1 |
|
MTBF(Year) |
150.86 |
115.68 |
131.97 |
153.41 |
|
MTTR(Hour) |
1 |
1 |
1 |
1 |
|
Operating temperature |
-5℃ ~ 50℃(normal operating temperature) |
|||
|
Storage temperature |
-40℃ ~ 70℃ |
|||
|
Relative humidity (non-condensing) |
5% RH to 95% RH, non-condensing |
|||
