Item |
Specification |
|
Computing |
Up to 2 Intel® Xeon® ® Processor Scalable Family, 4/6/8/10/12/14/16/20 cores, support up to 125W |
|
Memory |
16 DDR4 memory; Support up to 2666MT/s; Support RDIMM or LRDIMM, Up To 1TB capacity |
|
Storage Controller |
Standard array controller, support SATA RAID 0/1/10/5 Optional HBA card on Array card slot, support SATA/SAS RAID 0/1/10 Optional Array cards on Array card-specific slot, support RAID 0/1/10/5/6/50/60/1E/Simple Volume Optional standard PCIe 3.0 HBA and Smart Array card |
|
FBWC |
Support up to 2GB DDR3-1,866 MHz, 72-bit wide bus at 14.9 GB/s IO performance |
|
Local Storage |
Support SAS/SATA HDD/SSD hard disk; Maximum support 12LFF front mounted drive and 2 SFF rear mounted drive; Maximum support 25SFF front mounted drive and 4SFF + 2LFF rear mounted drive; Support up to 16 Front NVMe hard drives & Support 256GB SATA M.2 options |
|
Network |
Embedded 1Gbps HDM management network port; Optional 4×1GE electrical ports, 2×10GE Electrical Ports, 2×10GE optical ports through mLOM, mLOM Supports NCSI function, optional standard PCIE 3.0 network adapter options |
|
Expansion slot |
Upto 7 PCIe 3.0 slots (6 standard slots, 1 Array card slot) |
|
Ports |
Optional front VGA, Standard rear VGA, serial port, 5 USB 3.0 (1 front, 2 rear, 2 built-in), Optional 1 USB 2.0 and 2 MicroSD |
|
GPU Support |
Support 2 double wide GPU options upto 10.5” |
|
CD-ROM drive |
Support external/ built-in (4LFF/8SFF models only) |
|
Management |
HDM agentless management tools (with independent management port) and H3C FIST management software |
|
Power &Cooling |
Optional Platinum Level 550W/800W/1200W Optional Titanium Level 800W Optional Platinum Level 800W 336VHDC 1+1 redundant power supply Passed 80 Plus certification, up to 96% energy efficiency conversion rate Support hot-swappable redundant fans
|
|
Certification |
Support CCC, CECP, SEPA certification |
|
Temperature |
5℃～50℃ (Operating temperature is subjected to change with different configuration effects. Please refer to product technical documentation description for more details) |
|
Shape / Chassis depth |
87.5mm (H) * 445.5mm (W) * 735mm (D) (without security panel) |
|
Warranty |
3 Years Next Business Day Warranty |
