CPU |
2 4th Generation Intel®Xeon® Sapphire Rapids / 5th Generation Intel®Xeon® Emerald Rapids SP series 64 Cores for each Processor and 385W power consumption |
|
Chipset |
Intel® C741 |
|
Memory |
32 × DDR5 RDIMMs (maximum) Up to 5600 MT/s Data Rate, Dual-socket processor with maximum capacity of 8TB |
|
Storage controller |
Standard PCIe HBA Controller or Raid Controller NVMe RAID |
|
FBWC |
8 GB Cache, support Supercapacitor protection |
|
Storage |
Support SAS/SATA/NVMe U.2/EDSFF E1.S Drives Front 24LFF; Rear 12LFF+4LFF(2LFF)+4SFF; Support internal 4LFF or 8SFF*; Optional 18 NVMe drives* Support 2 M.2 as boot disk |
|
Network |
1 x onboard 1 Gbps HDM management Ethernet port 2 x OCP3.0 Ethernet adapter support NCSI function and hot-swap PCIe Standard Slots for 10/25/100/200Gb Ethernet Adapter or 100/200/400Gb InfiniBand card |
|
PCIe slots |
Up to 10 x PCIe 5.0 standard slots and 2x OCP3.0 Slots |
|
Ports |
2 x VGA connector (Front and Rear) and serial port 5 x USB 3.0 connectors (two at the front and two at the rear and one at the internal), 1 × Type C for HDM |
|
GPU |
Up to 2 double-width or 8 single-width GPUs* |
|
Optical drive |
External optical drive |
|
Management |
HDM Management System(with rear independent management Ethernet port and front dedicated Type C port) H3C iFIST/UniSystem U-Center data center management platform(Optional) |
|
Security |
Intelligent Front Security Bezel Support Chassis Intrusion Detection TPM2.0 2FA |
|
Power supply and Cooling |
1+1 Redundancy power supply Titanium 1600W Platinum Level 800W/1300W/1600W/2000W/2400W/2700W -48V/336V DC power module Hot swappable redundant Fans |
|
Standards |
CE CB TUV etc. |
|
Operating temperature |
Operating temperature: 5°C to 40°C (41°F to 104°F) Storage Temperature：-40~85ºC(-41°F to 185°F) The maximum operating temperature varies by server configuration. For more information, see the technical documentation for the device. |
|
Dimensions (H × W × D) |
4U Height Without a security bezel: 174.8 × 447 × 781 mm (6.88 × 17.60 × 30.75 in) With a security bezel: 174.8 × 447 × 809 mm (6.88 × 17.60 × 31.85 in) |
