CPU |
2 4th Generation Intel®Xeon® Sapphire Rapids / 5th Generation Intel®Xeon® Emerald Rapids SP series 64 Cores for each Processor and 385W power consumption |
|
Chipset |
Intel®C741 |
|
Memory |
32 DDR5 RDIMM Slots, 5600 MT/s Data Rate, 4 TB on 2 CPU Configuration Additional 16 expansion memory slots via CXL1 |
|
Raid Controller |
Dedicated PCIe HBA Controller or Raid Controller Standard PCIe HBA Controller or Raid Controller |
|
FBWC |
8 GB Cache, support Supercapacitor protection |
|
Storage |
29 Drives SAS/SATA HDD/SSD Drives,24 U.2 NVMe Drives SATA/NVMe M.2 Kit, DSD Model (2 x SD card kit) Front 12LFF bays, Rear 4LFF bays Front 25SFF bays, Rear 4SFF bays |
|
Network |
1 Onboard 1Gbps Management Network Port 2 Onboard OCP 3.0 Slots for 4 GE or 2 10GE or 2 25GE or 2 100GE NICs PCIe Standard Slots for 1/10/25/100/200GE Ethernet Adapter |
|
Expansion Slots |
10 PCIe Standard Slots (6 PCIe5.0 and 4 PCIe4.0) and 2 Onboard OCP 3.0 Slots; CXL1.1 |
|
Ports |
Standard:1 VGA Rear Port, 3 USB 3.0 Ports (1 Front, 2 Rear), 1 USB 2.0 Internal Port, 1 Management Port Optional: 1 Rear Management Port, Mounting Bracket Kit with Type-C port, 1 VGA port, 1 Management Port |
|
GPU |
8 Single-Slot or 4 Dual-Slot GPU Modules |
|
Optical Drive |
External Optical Disk Drive, Optional |
|
Management |
HDM Management System (with dedicated management port) H3C iFIST/UniSystem, LCD touchable model,64M Video Cache |
|
Security |
Intelligent Front Security Bezel Chassis Intrusion Detection TPM2.0 2FA for HDM Intel SGX2.0 |
|
Power supply |
1+1 Redundancy power supply Titanium 1600W Platinum 800W/1300W/1600W/2000W/2400W/2700W DC power supply Hot swappable Redundant Fans |
|
Standards |
CE，UL , FCC，VCCI，CB, etc. |
|
Operating temperature |
5°C to 45°C (41°F to 113°F) |
|
Dimensions (H × W × D) |
2U Height Without a security bezel: 87.5 x 445.4 x 780 mm (3.44 x 17.54 x 30.7 in) With a security bezel: 87.5 x 445.4 x 808 mm (3.44 x 17.54 x 31.8 in) |
