CPU |
2 AMD EPYC 9004 series processors 96 Cores for each Processor and 400W power consumption |
|
Memory |
24 DDR5 RDIMM or 3DS RDIMM Slots, 4800 MT/s Data Rate,3 TB on 2 CPU Configuration CXL1.1 |
|
Raid Controller |
Dedicated PCIe HBA Controller or Raid Controller* Standard PCIe HBA Controller or Raid Controller* |
|
FBWC |
8 GB Cache, support Supercapacitor protection* |
|
Storage |
41 Drives SAS/SATA HDD/SSD Drives,28 U.2 NVMe Drives, 28 E3.S Drives,40 E1.S Drives SATA/NVMe M.2 Kit, 2 DSD Model Front 12LFF bays, internal 4LFF bays, Rear 4LFF bays* Front 25SFF bays, internal 8SFF bays, Rear 8SFF bays* |
|
Network |
1 Onboard 1Gbps Management Network Port 2 Onboard OCP 3.0 Slots+1 Optional OCP 3.0 Slot for 4 GE or 2 10GE or 2 25GE or 2 100GE NICs PCIe Standard Slots for 1/10/25/100/200GE Ethernet Adapter |
|
Expansion Slots |
10 PCIe5.0 Standard Slots |
|
Ports |
Standard:1 VGA Rear Port, 4 USB 3.0 Ports (1 Front, 2 Rear, 1 Internal),1 Management Port Optional: 1 Rear Management Port, Mounting Bracket Kit with Type-C port, 1 VGA port, 1USB port, 1 Management Port |
|
GPU |
10 Single-Slot or 4 Dual-Slot GPU Modules |
|
Optical Drive |
External Optical Disk Drive, Optional |
|
Management |
HDM Management System (with dedicated management port) H3C iFIST/FIST, LCD touchable model,64M Video Cache |
|
Security |
Intelligent Front Security Bezel * Chassis Intrusion Detection TPM2.0 AMD Secure Processor(Root of Trust) |
|
Power supply |
Platinum 1300W/1600W/2000W/2400W (1+1 redundancy) Hot swappable Redundant Fans |
|
Standards |
CE，UL , FCC，VCCI，CB, etc. |
|
Operating temperature |
5°C to 45°C (41°F to 113°F) * |
|
Dimensions (H × W × D) |
2U Height Without a security bezel: 87.5 x 445.4 x 780 mm (3.44 x 17.54 x 30.7 in) With a security bezel: 87.5 x 445.4 x 808 mm (3.44 x 17.54 x 31.8 in) |
