Item

Description

Hardware

Fixed port

Four 10/100/1000Base-T Ethernet port

Independent reset key, function keys (Mesh, wireless optimization)

Wireless

4 built-in high gain omnidirectional antennas (2.4 GHz 3dBi & 5 GHz 5dBi)

CPU

Dual-core 1.0 GHz

Memory

512 MB

Indicator

Front LED: system status indicator

Rear LED: 1 WAN port status indicator, 3 LAN port status indicators

Dimensions (W×D×H)

95mm x 95mm x 226mm

Power supply

12V⎓2A

Cooling method

Natural cooling

Wireless

Wireless protocol

2.4 GHz: 802.11ax/n/g/b

5 GHz: 802.11ax/ac/n/a

Spatial flow

2.4 GHz 2x2 MIMO

5 GHz 4x4 MIMO

Wireless bandwidth

2.4G HT20/HT40

5G HT20/HT40/HT80/HT160

Wireless rate

Dual-frequency concurrency 5,378 Mbps

2.4 GHz: 574 Mbps & 5 GHz: 4,804 Mbps

Wireless roaming

Follow-up supporting of 11k/v

MU-MIMO

Upstream and downstream MU-MIMO
