Item

Description

Hardware

Fixed port

Four 10/100/1000Base-T Ethernet ports

Independent reset key, function keys (Mesh, wireless optimization)

Wireless

6 external high gain omnidirectional antennas (2.4 GHz & 5 GHz 5dBi)

CPU

Dual-core 1.0 GHz

Indicator

Front LED: system status indicator

Rear LED: 1 WAN port status indicator

Dimensions (W×D×H)

286mm x 87mm x 234mm

Power supply

12V⎓2A

Cooling method

Natural cooling

Wireless

Wireless protocol

2.4 GHz: 802.11ax/n/g/b

5 GHz: 802.11ax/ac/n/a

Spatial flow

2.4 GHz 2x2 MIMO

5 GHz 4x4 MIMO

Wireless bandwidth

2.4G HT20/HT40

5G HT20/HT40/HT80/HT160

Wireless rate

Dual-frequency concurrency 5,378 Mbps

2.4 GHz: 574 Mbps & 5 GHz: 4,804 Mbps

Wireless roaming

Support IEEE 802.11k/v

MU-MIMO

Upstream and downstream MU-MIMO

Software

Internet connection

Routing mode: DHCP/PPPoE/Static IP

Bridge mode: wired relay/wireless relay

EasyMesh

Support

IPv6

Support

Security features

WPA3 encryption

Anti-Wi-Fi squatting/anti-attack

Firewall, DMZ, DoS attacks

Network management

Guest Wi-Fi, access allow list/deny list, parental controls based on multiple periods, IP-based traffic control, Wi-Fi timing switch

Features

Qos traffic shaping, broadband password retrieval, packet fast-forwarding engine, virtual server, DDNS(NoIP, DynDNS), VPN(PPTP Client,L2TP Client)

Management method

Support for H3C Magic APP (iOS, Android), Web

Fault diagnosis

Link detection

Internet diagnosis

Operating environment

Operating temperature

0°C–40°C

Storage humidity

10%–90%, RH non-condensing
