CPU |
4 4th Generation Intel®Xeon® Sapphire Rapids SP series60 Cores for each Processor with 350W power consumption |
|
Chipset |
Intel®C741 |
|
Memory |
64 DDR5 RDIMM Slots, 4800 MT/s Data Rate |
|
Raid Controller |
Onboard SATA Raid Controller Standard PCIe HBA Controller or Raid Controller* |
|
FBWC |
8 GB Cache, support Supercapacitor protection* |
|
Storage |
27 SAS/SATA HDD/SSD Drives 26 U.2 NVMe Drives Supports PCIe NVMe storage accelerator card, Dual hot-swappable SATA M.2 Kit |
|
Network |
1 Onboard 1Gbps Management Network Port Onboard OCP 3.0 x16 Slots for 4 GE or 2 10GE or 2 25GE NICs PCIe Standard Slots for 1/10/25/40/100/200Gb Ethernet Adapter or 100/200Gb InfiniBand card |
|
Expansion Slots |
Up to 8 PCIe 5.0 x16 Standard Slots Up to 10 PCIe 5.0 x8 Standard Slots Up to 3 OCP 3.0 Slots |
|
Ports |
2 VGA Rear Ports (1 Front, 1 Rear), 4 USB 3.0 Ports (2 Front, 2 Rear),1 Management Port Optional: Mounting Bracket Kit with Type-C port, Power-Button, UID |
|
Optical Drive |
External Optical Disk Drive, Optional |
|
Management |
HDM Management System (with dedicated management port) H3C iFIST/FIST, LCD touchable model,64M Video Cache |
|
Security |
Intelligent Front Security Bezel * Chassis Intrusion Detection TPM2.0 Silicon Root of Trust 2FA for HDM Secure Decommissioning |
|
Power supply |
2 CRPS supplies, Compatible with expandable 4 power supplies (N+N redundancy) Titanium 1600W Platinum 850/1300/1600/2000/2400W Hot swappable N+1 Redundant Fans |
|
Standards |
CE，UL , FCC，VCCI，CB, etc. |
|
Operating temperature |
5°C to 45°C (41°F to 113°F) * |
|
Dimensions (H × W × D) |
2U Height Without a security bezel: 87.5 x 447 x 829 mm (3.44 x 17.60 x 32.63 in) With a security bezel: 87.5 x 447 x 857.5 mm (3.44 x 17.60 x 33.76 in) |
