CPU |
4 4th Generation Intel®Xeon® Sapphire Rapids SP series 60 Cores for each Processor and 350W power consumption |
Chipset |
Intel®C741 |
Memory |
64 DDR5 RDIMM Slots, 4800 MT/s Data Rate, Supports 32 Intel® Optane® persistent memory PMem 300 series |
Raid Controller |
Standard PCIe HBA Controller or Raid Controller* |
FBWC |
8 GB Cache, support Supercapacitor protection* |
Storage |
SAS/SATA HDD/SSD Drives U.2 NVMe Drives, Supports PCIe NVMe storage accelerator card Dual hot-swappable SATA M.2 Kit |
Network |
1 Onboard 1Gbps Management Network Port Onboard OCP 3.0 Slots for 4 GE or 2 10GE or 2 25GE NICs PCIe Standard Slots for 1/10/25/100/200GE Ethernet Adapter, InfiniBand card |
Expansion Slots |
Up to 10 x 16 PCIe 5.0 Standard Slots Up to 22 x 8 PCIe 5.0 Standard Slots 3 Onboard OCP 3.0 Slots |
Ports |
Standard:2 VGA Rear Port(1 Front, 1 Rear), 4 USB 3.0 Ports (2 Front, 2 Rear), 1 Management Port Optional: Mounting Bracket Kit with Type-C port, Power-Button, UID |
GPU |
Supports dual and Single-Slot GPU Modules |
Optical Drive |
External Optical Disk Drive, Optional |
Management |
HDM Management System (with dedicated management port) H3C iFIST/FIST, LCD touchable model |
Security |
Intelligent Front Security Bezel * Chassis Intrusion Detection TPM2.0 Silicon Root of Trust 2FA for HDM Secure Decommissioning |
Power supply |
4 CRPS supplies, 2000W(1N+N redundancy) Hot swappable Redundant Fans |
Standards |
CE,UL , FCC,VCCI,CB, etc. |
Operating temperature |
5°C to 45°C (41°F to 113°F) * |
Dimensions |
4U Height |
