Item

Specification

Dimensions (H × W × D)

27 × 155 × 58 mm (1.06 × 6.10 × 2.28 in)

Ports

8 × 10/100/1000BASE-T copper ports

Operating mode

Standard

Isolation

MAC address entries

4K

Switching capacity

16 Gbps

Forwarding capacity

11.9 Mpps

Packet buffering

1.5 Mbit

Switching mode

Store-and-forward switching

Power

12 V DC, 0.5 A

Auto-MDI/MDIX

Yes

Cooling method

Natural cooling

Operating temperature/storage temperature

0°C to 40°C (32°F to 104°F)/–40°C to +70°C (–40°F to +158°F)

Operating humidity/storage humidity

5% to 95% RH, noncondensing

Certifications

CE,RoHS

MTBF

> 50000 H

Installation method

Desktop-mount and wall-mount
