Item

Specification

Dimensions (H × W × D)

44 × 440 × 210mm (1.73 × 17.32 × 8.27 in)

Ports

16 × 10/100/1000BASE-T copper ports (2 uplink ports)

2 × 1000BASE-X SFP ports (uplink ports)

Operating mode

Standard

Isolation

Aggregation

Clone

MAC address entries

8K

Switching capacity

36 Gbps

Forwarding capacity

26.8 Mpps

Packet caching

4 Mb

Switching mode

Store-and-forward switching

PoE+

PoE+ supported

Supports PoE Power up to 225 W for all PoE ports(16 PoE ports)

Supports PoE Power up to 30 W for each PoE port

Power

100 to 240V AC

Auto-MDI/MDIX

Yes

Cooling method

Fan cooling

Operating temperature/storage temperature

0°C to 40°C (32°F to 104°F)/–40°C to +70°C (–40°F to +158°F)

Operating humidity/storage humidity

5% to 95% RH, noncondensing

Certification

CE,RoHS

MTBF

> 50000 H

Installation method

Rack-mount by using mounting brackets
