Item

Specification

Dimensions (H × W × D)

27 × 205 × 85 mm (1.06 × 8.07 × 3.35 in)

Ports

10 × 10/100/1000BASE-T copper ports

Operating mode

Standard

Isolation

MAC address entries

4K

Switching capacity

20 Gbps

Forwarding capacity

14.9 Mpps

Packet buffering

2 Mbit

Switching mode

Store-and-forward switching

PoE+

PoE+ supported

Supports PoE Power up to 57 W for all PoE ports(8 PoE ports)

Supports PoE Power up to 30 W for each PoE port

Power

54 V DC, 1.17 A

Auto-MDI/MDIX

Yes

Cooling method

Natural cooling

Operating temperature/storage temperature

0°C to 40°C (32°F to 104°F)/–40°C to +70°C (–40°F to +158°F)

Operating humidity/storage humidity

5% to 95% RH, noncondensing

Certifications

CE,RoHS

MTBF

> 50000 H

Installation method

Desktop-mount and wall-mount
