Technical specifications
|
Item |
Specification |
|
Dimensions (H × W × D) |
27 × 120 × 90 mm (1.06 × 4.72 × 3.54 in) |
|
Ports |
5 × 10/100/1000BASE-T copper ports |
|
MAC address entries |
2K |
|
Switching capacity |
10 Gbps |
|
Forwarding capacity |
7.4 Mpps |
|
Packet buffering |
1 Mbit |
|
Power |
5 V DC, 0.6 A |
|
Auto-MDI/MDIX |
Yes |
|
Cooling method |
Natural cooling |
|
Weight |
≤ 0.2 kg (0.44 lb) |
|
Operating temperature/storage |
0°C to 40°C (32°F to 104°F)/–40°C to +70°C (–40°F to +158°F) |
|
temperature |
|
|
Storage/operating humidity |
5% to 95% RH, noncondensing |
|
Certifications |
CE,RoHS |
|
MTBF |
> 50000 H |
|
Installation method |
Desktop-mount |
