Technical specifications
Item |
Specification |
Dimensions (H × W × D) |
27 × 155 × 58 mm (1.06 × 6.10 × 2.28 in) |
Ports |
5 × 10/100/1000BASE-T copper ports |
Operating mode |
Standard Isolation |
MAC address entries |
2K |
Switching capacity |
10 Gbps |
Forwarding capacity |
7.4 Mpps |
Packet buffering |
1 Mbit |
Switching mode |
Store-and-forward switching |
PoE+ |
PoE+ supported Supports PoE Power up to 57 W for all PoE ports (4 PoE ports) Supports PoE Power up to 30 W for each PoE port |
Power |
54 V DC, 1.17 A |
Auto-MDI/MDIX |
Yes |
Cooling method |
Natural cooling |
Operating temperature/storage temperature |
0°C to 40°C (32°F to 104°F)/–40°C to +70°C (–40°F to +158°F) |
Operating humidity/storage humidity |
5% to 95% RH, noncondensing |
Certifications |
CE,RoHS |
MTBF |
> 50000 H |
Installation method |
Desktop-mount and wall-mount |
