Item

Specification

Dimensions (H × W × D)

27 × 156 × 105 mm (1.06 × 6.14 × 4.13 in)

Ports

8 × 10/100/1000BASE-T copper ports

MAC address entries

4K

Switching capacity

16 Gbps

Forwarding capacity

11.9 Mpps

Packet buffering

1.5 Mbit

Power

12 V DC, 0.5 A

Auto-MDI/MDIX

Yes

Cooling method

Natural cooling

Weight

≤ 0.2 kg (0.44 lb)

Operating temperature/storage temperature

0°C to 40°C (32°F to 104°F)/–40°C to +70°C (–40°F to +158°F)

Storage/operating humidity

5% to 95% RH, noncondensing

Certifications

CE,RoHS

MTBF

> 50000 H

Installation method

Desktop-mount
